Durable Automotive PCB Assembly with 2-8 Layers and Immersion Tin Surface

Product Description:

Designed to meet the demands of the automotive industry, our PCB assembly supports 2-8 layers, providing ample flexibility for various automotive electronic systems. The double-sided design allows for increased component density and improved signal routing, making it ideal for complex automotive applications.

Our PCBA service for this product includes Surface Mount Technology (SMT), Through-Hole Technology (THT), and Fine Pitch Technology (FPT), ensuring compatibility with a wide range of electronic components commonly used in automotive systems.

Constructed with precision materials such as 0402 and BGA 0.5mm, our Automotive PCB Assembly guarantees reliable performance and durability. These materials are carefully selected to meet automotive industry standards and ensure the assembly can withstand the harsh conditions of automotive environments.

With a minimum hole size of 0.1mm, this PCB assembly is capable of accommodating various component types and sizes, allowing for versatile design options and enhanced functionality.

Whether you are designing engine control units, infotainment systems, or safety features for vehicles, our Automotive PCB Assembly provides the reliability and performance you need. Trust in our expertise and quality to deliver a PCB assembly that meets the rigorous demands of the automotive industry.

Features:

• Product Name: Automotive PCB Assembly
• Base Material: FR-4
• Application: Automotive Electronics
• Point: 359
• Hole Min: 0.1mm
• Pcb Gold Process: Immersion Gold

Technical Parameters:

Applications:

Automotive PCB Assembly is a crucial component in various automotive electronics applications, making it an essential part of the car engine assembly kit and industrial control PCB assembly. With a Hole Min size of 0.1mm, this product is designed to meet the high precision requirements of automotive electronics systems.

The versatility of Automotive PCB Assembly allows it to be used in a wide range of product application occasions and scenarios. Its compatibility with different surface finishes such as HASL, ENIG, OSP, Hard Plating, and Immersion Tin ensures optimal performance in various automotive electronic devices.

Automotive PCB Assembly is particularly suitable for applications in the automotive industry where reliable and high-performance PCBs are needed. Its standard Pcb Size of 220mm*186mm makes it suitable for use in different automotive electronic control units, sensors, displays, and communication systems.

Whether it is for engine management systems, infotainment systems, driver assistance systems, or other automotive electronics applications, Automotive PCB Assembly provides the necessary connectivity and reliability required in modern vehicles. Its Base Material of FR-4 ensures durability and stability in demanding automotive environments.

Overall, Automotive PCB Assembly offers a reliable solution for manufacturers in the automotive industry looking for high-quality PCBs for their products. Its superior performance, compatibility with various surface finishes, and precision design make it a preferred choice for Car Engine Assembly Kits, Industrial Control PCB Assembly, and other automotive electronics applications.

Customization:

Product Customization Services for the Automotive PCB Assembly include:

Material Quantity: 316 Pcs

Surface: HASL, ENIG, OSP, Hard Plating, Immersion Tin

Minimum Line Width: 3mil

Solder Mask Color: Green, Red, Blue, Black

Base Material: FR-4

Support and Services:

Our Product Technical Support and Services for Automotive PCB Assembly include:

- Comprehensive troubleshooting assistance for any issues related to the PCB assembly.

- Guidance on proper installation and use of the automotive PCB assembly.

- Support for software integration and compatibility with the PCB assembly.

- Regular software updates and patches to ensure optimal performance.

- Training resources and materials for customers to maximize the use of the product.

Packing and Shipping:

Product Packaging:

The Automotive PCB Assembly product will be carefully packaged in a sturdy cardboard box with ample protective padding to ensure safe transportation and delivery.

Shipping:

We offer reliable shipping services to ensure that your Automotive PCB Assembly product reaches you in a timely manner. Our shipping partners are experienced in handling delicate electronic components, providing a secure and efficient delivery process.

FAQ:

Q: What is Automotive PCB Assembly?

A: Automotive PCB Assembly is a printed circuit board specifically designed for use in automotive applications, providing electronic functionality within vehicles.

Q: What are the key features of Automotive PCB Assembly?

A: The key features of Automotive PCB Assembly include high temperature resistance, reliability, compact size, and the ability to withstand harsh automotive environments.

Q: How is Automotive PCB Assembly different from standard PCBs?

A: Automotive PCB Assembly is specifically designed and manufactured to meet the stringent requirements of the automotive industry, including resistance to vibrations, extreme temperatures, and exposure to chemicals found in vehicles.

Q: What are the common applications of Automotive PCB Assembly?

A: Automotive PCB Assembly is commonly used in various automotive electronic systems, including engine control units (ECUs), infotainment systems, advanced driver-assistance systems (ADAS), and lighting control modules.

Q: How can I ensure the quality of Automotive PCB Assembly?

A: To ensure the quality of Automotive PCB Assembly, it is important to source components from reliable manufacturers, adhere to automotive industry standards, conduct thorough testing procedures, and work with experienced PCB assembly providers with automotive expertise.
